Powerful 140 Max Thrust Horizontal Directional Drill with 10 Feet Drill Pipe Length and 000 Lbs Max Pullback Force
140 max thrust directional drill
,10 feet drill pipe length
,directional drill with max pullback force
| Attribute | Value |
|---|---|
| Weight | 18,000 Lbs |
| Mud Pump Pressure | 1,000 Psi |
| Max Pullback Force | 14,000 Lbs |
| Mud Pump Flow | 100 Gpm |
| Engine Power | 275 Hp |
| Engine | |
| Rod Length | 10 Feet |
| Drill Pipe Length | 10 Feet |
The XZ130F Horizontal Directional Drill is a powerful and efficient HDD drill rig designed to tackle a wide range of drilling projects with ease. With impressive features such as a Mud Pump Flow of 100 Gpm, Drill Pipe Diameter of 3.5 Inches, Max Torque of 10,000 Ft-lb, and Bore Diameter Range of 4.5-18 Inches, the XZ130F is a top choice for contractors looking for reliability and performance.
Equipped with a robust Mud Pump Flow of 100 Gpm, the XZ130F Horizontal Directional Drill ensures efficient and smooth drilling operations. This feature allows for effective removal of cuttings and helps maintain optimal drilling conditions throughout the project.
The Drill Pipe Diameter of 3.5 Inches on the XZ130F provides excellent stability and durability during drilling operations. With a sturdy and reliable drill pipe, users can trust the XZ130F to deliver consistent performance even in challenging soil conditions.
- Product Name: Horizontal Directional Drill (HDD Drill Rig)
- Mud Pump Pressure: 1,000 Psi
- Rod Length: 10 Feet
- Bore Diameter Range: 4.5-18 Inches
- Mud Pump Flow: 100 Gpm
- Warranty: One Year Or 2000 Working Hours
Rongchang Machinery's Horizontal Directional Drill XZ130F is a powerful and reliable HDD drill rig that is designed and manufactured in China. With a weight of 18,000 lbs, this drill rig is suitable for various applications and scenarios across different industries.
One of the key attributes of the XZ130F HDD drill rig is its mud pump that offers a flow rate of 100 GPM and a pressure of 1,000 psi. This ensures efficient drilling operations even in challenging soil conditions.
The XZ130F HDD drill rig is ideal for a wide range of product application occasions and scenarios. Whether it's utility installations, pipeline construction, or other underground construction projects, this drill rig can deliver exceptional performance.
Product Customization Services for the Horizontal Directional Drill product:
- Brand Name: Rongchang Machinery
- Place Of Origin: China
- Weight: 18,000 Lbs
- Max Pullback Force: 14,000 Lbs
- Max Thrust: 140,000 Lbs
- Max Carriage Speed: 200 Ft/min
- Max Torque: 10,000 Ft-lb
- Keywords: XZ130F, XZ450F, horizontal directional drilling rig
