12kHz DigiTrak DucTrak Transmitter 80ft Depth Used With F5 F2 SE Eclipse
Place of Origin:China
Brand Name:Rongchang Machinery
Minimum Order Quantity:1 pc
Price:Negotiable
Payment Terms:L/C,T/T,etc.
Product Details
Highlight:
DigiTrak DucTrak Transmitter
,12kHz DigiTrak DucTrak Transmitter
,DigiTrak DucTrak Transmitter 80ft Depth
Product Description
DigiTrak DucTrak™ transmitters are designed to track existing non-metal ducts to depths of 80 ft. These 12-kHz transmitters may be used with all receivers except the Mark Series.
DigiTrak DucTrak Transmitters
| DigiTrak DucTrak™ transmitters are designed to track existing non-metal ducts to depths of 80 ft (24.4 m). The DucTrak transmitters do not send out a roll/pitch signal and is not intended for horizontal directional drilling operations. These 12-kHz transmitters may be used with F5®, F2®, SE®, Eclipse®, and LT® systems. |
| DDT 12 DucTrak Extended Range Transmitter (12 kHz) | |
| Length x Diameter | 12 x 0.872 in. 30.48 x 2.22 cm |
| Depth Range | 80 ft 24.4 m |
| Battery Type | Type DL 123 3V lithium 8–12 hr life (approx.) |
| Temp. Range | 22 to 122° F -2.6 to 20° C |
| Weight | 8.4 oz 240 g |
| DDS 12 DucTrak Standard Range Transmitter (12 kHz) | |
| Length x Diameter | 6 x 0.872 in. 12.24 x 2.22 cm |
| Depth Range | 40 ft 12.2 m |
| Battery Type | Type DL 123 3V lithium 8–12 hr life (approx.) |
| Temp. Range | 22 to 122° F -2.6 to 20° C |
| Weight | 4.2 oz 127 g |
| Name | ID | Color | Price |
|---|---|---|---|
| DucTrak 6-in Transmitter | DDS | White | |
| DucTrak 12-in Transmitter | DDT | White |
